Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black

Optic Fiber Patch cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black

Product Description:

The SC connector was the first small form factor connector on the market. The use of a high performance 2.5mm ferrule gives the connector extremely high performance. SC connector comprises of a polymer body and a ceramic ferrule/sring/crimp barrel assembly plus a crimp over sleeve and rubber boot. These connectors are suitable for 900um and 2mm cables. The connector is precision made and manufactured to demanding specifications. The combination of a ceramic ferrule and a precision polymer housing provides consistent long-term mechanical and optical performance.

Optical Feature:

Low insertion loss, high return loss
Good in repeatability and exchangeability
High temperature stability
Excellent endface geometry
ISO9001:2008, ROHS
Various fiber cable length, jacket color, connector type and label, etc.
All products undergo 100% strict quality inspection before shipment.

Content		Testing Condition	(dB)
			SM			MM
			APC	UPC	PC
Optical Performance	IL(dB)	1310/1550nm LD Light	0.2	0.2	0.2	0.2
	RL(dB)	1310/1550nm LD Light	65	55	50	35
Environment Performance	High Temperature	+85℃,168H	0.2
	Temperature cycle	-40~+75℃,21cycle,168H	0.2
	Humidity thermal(Fixed)	5℃,95%R.H.,168H	0.2
	Humidity thermal cycle	10~+65℃,95%R.H.,21 cycle,168H	0.2
Mechanical Performance	Vibration	10~55Hz,1.5mm(p-p)	0.1
	Bending	0.9kgf,-90°~+90°,100cycle	0.1
	Torsion	2.5kgf,10times/min,±180°,200times	0.1n
	Anti-tension	90N,10min	0.1
	Dropping	1.5 height, 8 times	0.2
	Repeat	10 Times inserts	0.1
	Durability	>1000times	0.2
