SC UPC APC G652D G657A PVC LSZH Fiber Optic Patch Cord

Ask Lasest Price
Brand Name :	Weiroct
Model Number :	SM MM
Certification :	ISO-9001
Price :	USD2-12/set
Payment Terms :	T/T, L/C, Western Union, MoneyGram
Supply Ability :	1000pcs/day
Delivery Time :	5~20 DAYS

Add to Cart

Product Details
Company Profile

SC UPC APC G652D G657A PVC LSZH Fiber Optic Patch Cord

SC UPC APC G652D G657A PVC LSZH customized fiber optic patch cord

Product Description of SC/APC to SC/APC Singlemode Simplex LSZH fiber optic patch cord:

* The fiber optic patch cord mainly used on patch panel or for the connection between outlets and terminal equipment.

* It also widely used for high bit rate data
transmission,telecommunications,tesing instruments,active device
terminations,LAN/WAN and FTTX.
* Fiber Optic Patch cords are ultra reliable components featuring
low insertion loss and return loss.

* They come with your choice of simplex or duplex cable
configuration .

* Extensive range of fiber patch cables are terminated with
state-of-the-art connectors and available in any combination of ST,
SC, LC ,FC and

MTRJ with PC, UPC or APC polish types to meet your standard or
custom configurations.

Features of SC/APC to SC/APC Singlemode Simplex LSZH fiber optic patch cord:

1. Low insertion loss and back reflection loss,

2. Good repeatability,

3. Good interchangeability

4. High temperature stability

5. Good durability

6. Superior Quality Standard PC/UPC/APC Polishing

Specification

Item	Unit	LC/SC/FC/ST Fiber Patch Cord
Item	Unit	SM			MM
Fiber Diameter	UM	9/125			65.5/125	50/125
Polishing		PC	UPC	APC	PC	PC
Insertion Loss	dB	≤0.2	≤0.15	≤0.2	≤0.1	≤0.1
Return Loss	dB	≥55	≥50	≥60	≥35dB	≥35dB
Insert-pull Test	dB	≤0.2	≤0.2	≤0.3	≤0.15	≤0.15
Interchangeability	dB	≤0.1	≤0.1	≤0.15	≤0.1	≤0.1
Temperature Range	℃	-40~+80
Durability(1/Matings)	≥1000
Tensile Strength (N)	≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9
Fiber	9/125um, 50/125um,62.5/125um,ect
Diameter	0.9mm 2.0mm, 3.0mm etc
Cores	Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc

Other type

SC UPC APC G652D G657A PVC LSZH Fiber Optic Patch Cord

FAQ

Q1. Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity.
Q3. Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for the product?
A: Firstly let us know your requirements or application.
B. Secondly We quote according to your requirements or our suggestions.
C. Thirdly customer confirms the samples and places deposit for formal order.
D. Fourthly We arrange the production.
