FTTH Equipment 1x12 PLC Splitter Optical Fiber With SC/APC Connector FTTH Cassette

Description :

PLC Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. Oxin provides whole series of 1xN splitter and 2xN splitter products that are tailored for specific applications.

Application:

* Can be used for FTTX Systems
* Passive Optical Networks (PON)
* CATV TV Networks (CATV)
* Optical Signal Distribution

Item	1x12
Operating Wavelength(nm)	1260-1650
Fiber Type	G657A1 or as customers' order
Connector	SC/FC/LC
Ferrule section	UPC/APC
Insertion loss(dB)	≤12.8
Loss uniformity(dB)	≤1.2
Return Loss(dB)	≥55
Polarization Dependent Loss(dB)	≤0.25
Directivity(dB)	≥55
Temperature correlation loss	≤0.5
-40～85℃(dB)
Size(mm)(LxWxH)	60×7×4
Working Temperature(℃)	-40～85
Storage Temperature(℃)	-40～85
