Ftth fiber cable G-Fiber GJXFH Outdoor 1 2 4 6 8 Core Figure 8 Fiber Optic Cable price per meter FTTH Drop Cable

Characteristics

--- Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property

--- Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber

--- Simple structure, light weight and high practicability

--- Novel flute design, easily strip and splice, simplify the installation and maintenance

Fiber Characteristic:

Technical data:

strength member	material	Galvanized steel wire/FRP/KFRP
	diameter	2*(0.5~0.8)mm
Self support Messenger wire	material	Galvanized steel wire
	diameter	1.0mm
Outer sheath	material	LSZH
	diameter	1.8±0.2mm
Cable size (Height * width)	2.0(±0.1) mm × 5.2(±0.2)mm
Cable sheath thickness	Max. 0.8mm/Min. 0.4mm
Messenger sheath thickness	0.5~0.7mm
Cable weight	1~2core	18.2KG
	4-6 core	18.5KG
	8~24core	54KG

Optical Characteristics

G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20°C)	@850nm			≤3.5 dB/km	≤3.5 dB/km
	@1300nm			≤1.5 dB/km	≤1.5 dB/km
	@1310nm	≤0.45 dB/km	≤0.50 dB/km
	@1550nm	≤0.30 dB/km	≤0.50dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc		≤1260nm	≤1480nm

More products

Indoor cable

Outdoor cable

FAQ

1.Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.

2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.

3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.

4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.

5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
