24pcs Tight Buffered Fiber , 0.5mm FRP GJFJH Indoor Fiber Cable

Indoor Tight Buffered Fiber Optic Cable GJFJH Indoor Distribution Cable

Product Description:

1. Indoor fiber optical cable is made by evenly applying strands of
Aramid yarns as the strength member over tight buffer fibers and
then is completed with a flame-retardant sheath.

2. 2 fiber, single mode or multimode, Tight buffer fiber, Aramid yarn, LSZH jacket.

Cable Specification:

Item Name:Fiber optical cable GJFJV

Optical Mode:Singlemode/Multimode

Outder Diameter: 6.5mm-6.8mm

Working Life:More than 25 years

Application:Office/Comercial Building,optical test equipment,communication base station/distribution box,residential area

Products Features:

Small diameter,light weight,flame retardant,excellent strippability

Low-attenuation,High flexibility

Standards and Certificate:

Cable complies with Standard YD/T 769-2003.

Storage/Operating Temperature: -40°C to + 70°C

Certificate:CE ROHS ISO9001

Cable diameter:

	MPC-02	MPC-04	MPC-06	MPC-08	MPC-10	MPC-12
Cable Diameter(mm)	4.1+-0.25	4.8+-0.25	5.1+-0.25	6.2+-0.25	6.5+-0.25	6.8+-0.25
Cable Weight(kg/km)	12	20	24	29	32	35
Tight Buffer Fiber Diameter	900+-50μm

Mechanical Characteristics:

Tensile Strength	Long Term	80N	60	50
Tensile Strength	Short Term	150N	120	100
Crush Resistance	Long Term	100N/100mm	100N/100mm	100N/100mm
Crush Resistance	Short Term	500N/100mm	500N/100mm	500N/100mm
Bending Radius	Dynamic	20XD	20XD	20XD
Bending Radius	Static	10XD	10XD	10XD

Fiber Count	Outside OD(mm)	Tight Buffer OD(mm)	Weightkg/km	Tensile Strength(N)		Crush Resistance(N/100mm)		Bending Radius(mm)
2	3	0.9	15	600	200	1000	200	20D	10D
4	5	0.9	22	600	200	1000	200	20D	10D
6	5	0.9	23	600	200	1000	200	20D	10D
8	5.5	0.9	28	600	200	1000	200	20D	10D
12	6	0.9	38	600	200	1000	200	20D	10D
16	7.2	0.9	42	600	200	1000	200	20D	10D
24	8.3	0.9	58	600	200	1000	200	20D	10D
48	10	0.9	96	600	200	1000	200	20D	10D
